OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
5.4.3 HIGHPRESSURE FILTER OPTION
Closed
Open
Preferred installation
position of the high
pressure  lter
To ensure problem-free operation it is recommended that a
WAGNER high pressure  lter be used. These have been developed
especially for WAGNER pneumatic pumps. The  lter inserts can be
exchanged depending on the material to be used. The respective
high pressure  lters and their inserts for the device can be found
in the accessories list.
1 Fluid section connection
2 Material outlet
3 Return line
up to 530 bar; 7687 psi
B_04064
2
3
1
Open
(Return line)
Closed
(Spraying)
up to 270 bar; 3916 psi
