Jaguar air motor spare parts list
220 mm / stroke 150 mm
8.7 inches / stroke 6 inches
Designation Order No.
1 Air motor 2329625
2 1 Flange 369316
3 1 Piston rod 368402
4 1 Cylinder pipe 369403
5 2 Compressed air pipe 368404
6 1 Control air pipe 367405
8 1 Sealing plug 369307
9
2 Outlet seal 369312
10 1 Connecting part 369309
11 1 Silencer 369310
12 1 Hood 369905
13
1 Filter, compressed air 369313
14 1 Control air lter 367314
15 1 Fluid warning label 2332082
16 1 Shoulder screw 369318
17
1 Sound deadening pad 369906
18 2 Cotter pin 369320
23 1 Filter holder 367324
25 1 Throttle 367325
28
6 O-ring 9974143
29 2 Rod seal 9974217
30 2 Pilot valve 369290
= Wearing part
= Included in service set
11.3.4 JAGUAR AIR MOTOR
Incorrect maintenance/repair!
Risk of injury and equipment damage.
Have repairs and part replacements be carried out only by
specially trained sta or a WAGNER service center.
Before all work on the device and in the event of work
interruptions:
- Switch o the energy/compressed air supply.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Observe the operating and service instructions at all times when
carrying out work.
