64
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Fluid sections spare parts list
Designation Order No. Order No.
1 Fluid section 2329660 2329662
2 1 Pipe 369502
3 1 Cylinder 369503
4 1 Inlet housing 369504
5
1 Piston 369505
6 1 Valve screw 369506
7 1 Ball guide, inlet 369507
8 1 Connecting ange 369501
9 1 Valve seat inlet (carbide) 369509
10 1 Valve seat outlet (carbide) 369510
11 1 Snap ring ange 369511
12 2 Snap ring half 369512
13 1 Securing ring 369513
16 1 Support ring 369516
17 1 Pressure ring 368519
18 1 Support ring 369518
19 1 Pressure ring 369519
20
2 Sealing collar TG 368522
20 2 Sealing collar T 368900
21 3 Sealing collar PE 368523 368523
22 2 Sealing collar TG 369522
22 2 Sealing collar T 369900
◆ = Wearing part
★ = Included in service set
= Not part of the standard equipment but available as a special accessory.
11.4 FLUID SECTIONS
11.4.1 FLUID SECTION 300 CM³
Incorrect maintenance/repair!
Risk of injury and equipment damage.
Have repairs and part replacements be carried out only by
specially trained sta or a WAGNER service center.
Before all work on the device and in the event of work
interruptions:
- Switch o the energy/compressed air supply.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Observe the operating and service instructions at all times when
carrying out work.
WARNING
