67
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Fluid sections spare parts list
Designation Order No.
1 Fluid section 2329679
2 1 Pipe 369552
3 1 Cylinder 369553
4 1 Inlet housing 369554
5
1 Piston 369555
6 1 Valve screw 369556
7 1 Ball guide, inlet 369507
8 1 Valve screw inlet 369558
9 1 Valve seat inlet (carbide) 369509
10 1 Valve seat outlet (carbide) 368509
11 1 Connecting  ange 369551
16 1 Support ring 369566
17 1 Pressure ring 369567
18 1 Support ring 369568
19 1 Pressure ring 369569
20
2 Sealing collar TG 369570
21 3 Sealing collar PE 369571
22 2 Sealing collar TG 369572
23 3 Sealing collar PE 369573
25 2 O-ring 369575
27 1 O-ring 369527
28 1 O-ring 9971464
31 1 Separating agent cup 368531
32 2 Coupling cover 368532
40 1 Spirawave, crest-to-crest 9998834
= Wearing part
= Included in service set
11.4.2 FLUID SECTION 600 CM³
Incorrect maintenance/repair!
Risk of injury and equipment damage.
Have repairs and part replacements be carried out only by
specially trained sta or a WAGNER service center.
Before all work on the device and in the event of work
interruptions:
- Switch o the energy/compressed air supply.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Observe the operating and service instructions at all times when
carrying out work.
WARNING
