Fluid sections spare parts list
Designation Order No. Order No.
23 3 Sealing collar PE 369523 369523
25 2 O-ring 369525
27 1 O-ring 369527
28 1 O-ring 369528
31 1 Separating agent cup 368531
32 2 Coupling cover 368532
40 1 Spirawave, crest-to-crest 9998671
41 1 Spirawave, crest-to-crest 9998671
42 1 Ball (large) 9943086
43 1 Ball (small) 9941505
44 1 O-ring 9974117
45 1 O-ring 9974116
46 1 O-ring 9974118
50 4 Hexagon bolt 9907149
51 3 Washer 9920107
52 3 Hexagon bolt 9900157
53 3 Threaded bolt 368533
54 1 Shoulder ring 369514
55 4 Washer 9925011
56 1 Rotary connection G3/4" 2329923
57 1 Fitting DF-MM-R1½"-M36-PN15-SSt 2329563
58 1 Sealing sleeve 2329898
60 Mobilux EP 2 grease 9998808
61 1 Anti-sieze paste, 100 g 9992609
62 Molykote DX grease 9992616
Packing, upper:
100
1 Packing PE/TG, complete 368991
101 1 Packing PE/T, complete 368992
Packing, lower:
103 1 Packing PE/TG, complete 369991
104 1 Packing PE/T, complete 369992
Valve seat, stainless steel:
105 Valve seat set 300, in stainless steel version,
consisting of: pos. 9, 10, 27, 28
2331586
Service sets:
Service set PE/TG 369990
Service set PE/T 369964
◆ = Wearing part
★ = Included in service set
= Not part of the standard equipment but available as a special accessory.
