73
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Incorrect maintenance/repair!
Danger to life and equipment damage.
Only a WAGNER service center or a suitably trained person may
carry out repairs and replace parts.
Only repair and replace parts that are listed in the chapter "Spare
Parts Catalogue" and that are assigned to the device.
Before all work on the device and in the event of work
interruptions:
- Disconnect the control unit from the mains.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Observe the operating and service instructions at all times when
carrying out work.
WARNING
Ball valve version in: Stainless steel
Designation Order No.
1 1 HD lter DN10-PN270 SSt, complete 2329024
2 1 Filter housing 2324542
3 1 Union nut 2324543
4 1 Reducing double nipple with 2x60° 2325826
5
1 O-ring 9955863
7 1 Distribution housing 2324544
8 1 Relief valve 169248
10 1 Filter support 9894245
11
1 Filter cartridge *
* Filter cartridge 200 295721
* Filter cartridge 100 3514068
Filter cartridge 50 3514069
Filter cartridge 20 291564
12 1 Cone spring 3514058
13 1 Outlet pipe 2324552
21 1 Pressure ring d45 2325562
23 1 Hexagon plug 2323718
34 1 Loctite 542 50 ml; 50 cc 9992831
35 1 Mobilux EP 2 grease 9998808
36 1 Anti-sieze paste tube 9992609
37 1 Molykote DX grease 9992616
= Wearing part
= Not part of the standard equipment but available as a special accessory.
