Figure 1–1: 30-cm CH or 30-cm CHC module mounted next to the ACQUITY Arc or
ACQUITY Arc Bio system stack
Detector
30-cm CH or 30-cm CHC module
30-cm column-compartment adapter bracket
ACQUITY Arc Quaternary Solvent Manager-R (QSM-R) or ACQUITY Arc Bio Quaternary
Solvent Manager-R (bioQSM-R)
ACQUITY Arc Sample Manager Flow Through Needle-R (SM FTN-R) or ACQUITY Arc Bio
Sample Manager Flow Through Needle-R (bioSM FTN-R)
December 5, 2017, 715004751 Rev. C
Page 12
