B Specifications
B.1 30-cm CH and 30-cm CHC physical specifications
Attribute Specification
Height 57.1 cm (22.5 inches)
Width 15.2 cm (6.0 inches)
Depth (without drip tray
fitting)
54.3 cm (21.4 inches)
Weight 30-cm CH: 10.0 kg (22.0 pounds)
30-cm CHC: 12.7 kg (28.0 pounds)
Access to passive
preheater, column, and
valve tubing
Inside column compartment via access door
Number of columns One, 300-mm column with guard; two, 300-mm columns with
guards; or three, 300-mm columns with guards
Column sizes 7.8-mm ID maximum
Column guards up to 20 mm maximum length
Column selection As many as three columns with optional, 3-column selection valve kit
[8 port, 65,500 kPa, (655 bar 9500 psi)]
B.2 30-cm CH and 30-cm CHC environmental specifications
Attribute Specification
Operating temperature range 4 to 40 °C
Operating humidity range 20 to 80%, non-condensing
Shipping and storage temperature range -30 to 60 °C
Shipping and storage humidity range 20 to 85%, non-condensing
December 5, 2017, 715004751 Rev. C
