Wiring the lower D connector

Function

Input

or

output

Configurable Signal response

TACHO FREQUENCY

TACHO F Hz

No

TACHO

TACHO mA

No 4-20mA

TACHO 0-10V

No 0-10V

28 m-630un-en-08
