Function

Input

or

output

Configurable Signal response

TTL 1

TTL OUT 1

Yes

Output 1

TTL 2

TTL OUT 2

Yes

Output 2

DIRECTION

DIRECTION

DIRECTION

No

m-630un-en-08 29
