Waveshare RS232/485 TO WIFI POE ETH (B) - 3.3 PRODUCT APPEARANCE

RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
11
WIRELESS
SPECIFICATION
+17dBm(Max.@HT20,MCS7)
+17dBm(Max.@HT40,MCS7)
Configured by users
Receiving
sensitivity
802.11
b
:-89
dBm
（@11
Mbps
）
802.11
g
:-81
dBm
（@54
Mbps
）
802.11n:-73dBm（@HT20,MCS7）
-71dBm（@HT40,MCS7）
HARDWARE
SPECIFICATION
Data port
RS232, RS4
85: 300~460.8
Kbps
RS232 port(ESD/EFT protection)
RS232 port(ESD/EFT/surge protection)
Network port
Ethernet: 10
Mbps
/100
Mbps
Operating
voltage
DC6～36V
Operating
temperature
-40℃～85℃
Dimensions
109.66*28*64.71mm（L*W*H）
Software
parameters
Wireless network
Station/AP/AP+Station
mode
Security
mechanism
WPA PSK/WPA2 PSK
Encryption type
TKIP/AES
Operating mode
transparent transmission mode, protocol
transmission mode
Command setting
AT+Command Structure
Protocol
TCP/UDP/ARP/ICMP/DHCP/DNS/HTTP/MQTT
Maximum TCP
connections
24
User
Configuration
Web Server+AT Command Configuration
Customer
application
software
Support customer customization of application
software
3.3 PRODUCT APPEARANCE
The following image shows the appearance of RS232/485 TO WIFI ETH (B):
