RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
2. QUICK GET START
The RS232/485 TO WIFI POE ETH (B) serial server supports the functions of UART to WIFI, UART
to Ethernet, and Ethernet to WIFI. It can convert the RS485 serial port into a TCP/IP network interface
and achieve bidirectional transparent data transmission between the RS485 serial port and
WIFI/Ethernet.
This chapter provides a quick start introduction for the RS232/485 to WiFi POE ETH (B) serial
server. We recommend users to seriously read this chapter and follow the instructions step by step.
This will give you a comprehensive understanding of the product. Users can also choose to read
specific chapters based on their interests and needs. For specific details and explanations, please refer
to the following chapters.
This section primarily provides a quick start guide for the RS232/485 TO WIFI POE ETH (B) device
in AP mode.
The following software is involved: SSCOM.exe: Serial Debugging Assistant.
2.1 HARDWARE CONNECTION
The default configuration for RS232/485 to WiFi POE Ethernet (B) is as follows:
Figure RS232/485 TO WIFI POE ETH (B) default configuration
In order to test the communication conversion of RS232/485 to WiFi/Ethernet, we will connect
the serial port of the RS232/485 to WiFi POE Eth (B) serial server to the serial port of the computer.
