RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
Figure data carrying registration package diagram
Parameters related to this function are set in the "serial port and other settings" section of the
webpage, which is disabled by default.
The relevant instruction settings are as follows:
Table Registration Package Command List
Set registration packet type
Registration packet setting
Set/query transparent cloud account and password
Set/query user-defined registration package content
6.10 CUSTOMIZED HEARTBEAT PACKETS
In the network transparent transmission mode, users can choose to turn on the custom
heartbeat packet function, and heartbeat packet can choose to send it to the network server or the
serial port device. The schematic block diagram is as follows:
