Waveshare RS232/485 TO WIFI POE ETH (B) User Manual

RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
15
Figure Outline dimensions
3.7 APPLICATION SCENARIOS
The application scenarios of RS232/485 to WiFi/Ethernet is as shown below:
 The seial port (RS232/485) to WiFi ETH (B) are as follows:

WiFi remote control/monitor, TCP/ip and WiFi co-processor.
 WIFI remote control in the field of toys such as airplanes and cars.

WIFI network radio, camera, digital photo frame;
 Medical instrument, data acquisition device, handheld devices.

Wi-Fi body fat scale, smart card terminal and smart home.
 Instruments and meters, equipment parameter monitoring, wireless POS machine;

Other wireless related secondary development and application in modern agriculture and
military fields;

Smart factories, smart homes, smart medical care and other fields.

Waveshare RS232/485 TO WIFI POE ETH (B) Specifications

General

Model	RS232/485 TO WIFI POE ETH (B)
Serial Interface	RS232/RS485
WiFi Standard	802.11 b/g/n
Ethernet Speed	10/100Mbps
Network Interface	Ethernet
Power Supply	PoE
Operating Temperature	-40°C to 85°C
Humidity	5% ~ 95%
