RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
AT+WMODE=AP
(2) Parameters under the WiFi serial server's Access Point (AP) mode can be selected and
configured based on your requirements or you can use the default parameters. Here's an example of
parameter settings:
At+WAP = 11bgn, waveshare-test, auto (optional)
AT+WAKEY=WPA2PSK,AES,12345678 (optional)
(3) Restart the WIFI serial server:
AT+Z
Complete the parameter setting.
Note:
1. All settings set to the AT command need to enter the AT command mode (please refer to
“RS232/485 TO WIFI POE ETH (B) AT instruction set” for details).
2. After the parameters are set, they need to be "restarted" to take effect, so as to refresh the
original configuration information in the memory and restart the operation, which will not be
described in detail later.
5.2.2 WIRELESS NETWORKING APPLICATION (STA)
RS232/485 TO WIFI POE ETH (B) serial server is connected to other AP (such as routing in local
area network) as a STA to form a wireless network. All STAs regard this AP as the center of the
wireless network, and the mutual communication between STAs is completed through the AP, as
shown in the following figure:
Figure Wireless networking application (STA)
The parameters of WIFI serial server are set as follows:
(1) Set the working mode of the WIFI serial server:
