4. PRODUCT PARAMETERS SETTING
The RS232/485 TO WIFI POE ETH (B) serial server supports AT command and Web parameter
setting. For the setting of AT command, please refer to the chapter of "AT instruction set" in the
document. This chapter mainly explains how to set up the Web.
4.1 WEB MAN AGEMENT PAGE
When using RS232/485 TO WIFI POE ETH (B) serial server for the first time, it is necessary to
configure the WIFI serial server. You can connect the AP interface of RS232/485 TO WIFI POE ETH (B)
through a PC and configure it with a web management page.
By default, the AP interface SSID of RS232/485 TO WIFI POE ETH (B) is Waveshare_xxxx, and the
IP address, user name and password are as follows:
Table Network Default Settings
Specifications
Default
SSID
Waveshare_xxxx
IP Address
10.10.100.254
subnet mask
255.255.255.0
user name
admin
password
admin
4.1.1 OPEN THE MANAGEMENT PAGE
Firstly, connect RS232/485 TO WIFI POE ETH (B) with the wireless network card of PC, and the
SSID is Waveshare_xxxx. When connected, open the browser, enter 10.10.100.254 in the address bar
and press enter. Fill in the user name and password in the pop-up dialog box, and then "confirm".
Figure the second step of opening the management web page
Then; The RS232/485 TO WIFI POE ETH (B) management page supports Chinese and English, and
can be set in the upper right corner. It is divided into 9 pages, namely, quick configuration, mode

Waveshare RS232/485 TO WIFI POE ETH (B) Specifications

General

Model	RS232/485 TO WIFI POE ETH (B)
Serial Interface	RS232/RS485
WiFi Standard	802.11 b/g/n
Ethernet Speed	10/100Mbps
Network Interface	Ethernet
Power Supply	PoE
Operating Temperature	-40°C to 85°C
Humidity	5% ~ 95%
