Waveshare RS232/485 TO WIFI POE ETH (B) User Manual

RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
18

Device management: When all the above parameters are configured, click Restart to restart the
module.
4.1.3 MODE SELECTION PAGE
The first page of the Web can be set to select RS232/485 TO WIFI POE ETH (B) serial server to
work in AP mode or STA mode.
"Data transmission mode" the working modes of WIFI serial server are transparent transmission
mode, serial command mode, HTTPDClient mode and ModbusTCP<=>ModbusRTU mode.
Figure wireless mode settings
4.1.4 WIRELESS ACCESS POIN T SETTINGS PAGE
RS232/485 TO WIFI POE ETH (B) supports AP interface, through which the WIFI serial server can
be managed very conveniently, and the self-organizing network can be realized. The management
page is shown below. Including the setting of SSID, wireless network mode and wireless security, and
the setting of local area network composed of AP.

Waveshare RS232/485 TO WIFI POE ETH (B) Specifications

General

Model	RS232/485 TO WIFI POE ETH (B)
Serial Interface	RS232/RS485
WiFi Standard	802.11 b/g/n
Ethernet Speed	10/100Mbps
Network Interface	Ethernet
Power Supply	PoE
Operating Temperature	-40°C to 85°C
Humidity	5% ~ 95%
