(1) set the No.1 WiFi serial server as STA.
AT+WMODE=STA
For No.2 WIFI serial server, set it as AP.
AT+WMODE=AP
(3) No.1 WIFI serial server is connected to AP(WIFI serial server 2) as a STA, so the SSID and password
to be connected to WIFI serial server 1 are the AP parameters of WIFI serial server 2.
The SSID and password of No.2 WIFI serial server can be queried by using the following AT
instructions:
AT+WAP
AT+WAKEY
You can also choose settings as required, or use default parameters. Examples of parameter
settings for WIFI serial server 2 are as follows:
At+WAP = 11bgn, waveshare-test, auto (optional)
AT+WAKEY=WPA2PSK,AES,12345678 (optional)
An example of parameter setting for No.1 WIFI serial server is as follows (set the SSID and
password of WIFI serial server 2 corresponding to the connected AP parameters), as follows:
AT+WSSSID=RS232/485 TO WIFI POE ETH (B)-TEST
AT+WSKEY=WPA2PSK,AES,12345678
Consistent with the parameter setting example of WIFI serial server 2.
(4) Restart the WIFI serial server:
AT+Z
Complete the parameter setting.
5.3 WIRED NETWORKING SETUP
Related AT commands are as follows:
Table related AT command list
Item
Note
1
WMODE
Set/query WIFI operation mode (AP, STA)
2
WSSSID
Set/query the SSID of the associated AP
3
WSKEY
Set/query the encryption parameters in WIFISTA mode
4
WANN
Set/query STA network parameters
5
WSLK
Query STA wireless connection status
6
WAP
Set/query the parameters in WIFI AP mode
