Waveshare RS232/485 TO WIFI POE ETH (B) User Manual

RS232/485 TO WIFI POE ETH (B) User Manual
www.waveshare.com
2
1. OVERVIEW
Features:

Support 802.11b/g/n wireless standard.
 Supports fast networking protocol.

Support router and bridge modes.
 Supports communication via RS232/485 to WiFi and Ethernet interfaces.

Rich status indicator: PWR, LINK, RXD, TXD.
 Wide-range voltage DC 6-36V input, supporting screw terminals, power supply and PoE Ethernet
port power supply.
 The operating modes can be selected as transparent transmission mode, serial command mode,
HTTP Client Mode, Modbus mode, and AT command mode.
 Support registering MAC, transparent cloud, and customized registration packets.

Supports custom heartbeat packets, socket distribution protocols, and Modbus polling functions.
 Support timeout reboot, timed reboot function and so on.

Support MQTT function, can access Ali cloud and other IoT cloud platforms.
 Support hardware watchdog, making the system more stable.

Supports serial port free framing and automatic framing, resulting in higher forwarding
efficiency.

Support Websocket function to achieve real-time interaction between serial ports and web
pages.
 Support four parameter configuration methods: web page, software settings, serial AT command,
and network AT command.

Supports one click (pressing the RELOAD button for more than 5 seconds) to restore factory
settings.

Long communication distance, with two serial servers transmitting 150 meters to each other.
 Guide rail design for easy and convenient installation.

Waveshare RS232/485 TO WIFI POE ETH (B) Specifications

General

Model	RS232/485 TO WIFI POE ETH (B)
Serial Interface	RS232/RS485
WiFi Standard	802.11 b/g/n
Ethernet Speed	10/100Mbps
Network Interface	Ethernet
Power Supply	PoE
Operating Temperature	-40°C to 85°C
Humidity	5% ~ 95%
