30 BlueCool S-Series
13 Technical Data
13.1 Self-contained air-conditioning units BlueCool S-Series 230 V
Type
S6-R-230V-
REV-R410a
S8-R-230V-
REV-R410a
S10-R-230V-
REV-R410a
S13-R-230V-
REV-R410a
S16-R-230V-
REV-R410a
S20-R-230V-
REV-R410a
S27-R-230V-
REV-R410a
Cooling capacity [BTU/h] *1 6,000 8,000 10,000 13,000 16,000 20,000 27,000
Cooling capacity [kW] *1 1.8 2.4 2.9 3.8 4.7 5.9 7.9
Rated voltage [V] 230
Frequency [Hz] 50/60
Current consumption, operation [A] 50Hz *2 2.0 - 2.4 2.4 - 3.5 2.6 - 4.0 3.6 - 7.1 4.9 - 7.1 5.9 - 8.9 7.0 - 10.5
Max. starting current intake, current peak [A]
50 Hz
14 28 27 37 54 60 77
Starting current intake RMS40 [A] 50 Hz *3 5 17 17 22 35 39 49
Starting current intake RMS300 [A] 50 Hz *4 3 9 9 11 19 20 32
Max. starting current intake, current peak
with soft start [A] 50 Hz
11 12 11 13 22 23 34
Current consumption RMS40 with soft start
[A] 50 Hz *3
4 7 7 7 12 14 19
Current consumption RMS300 with soft start
[A] 50 Hz *4
3 5 5 5 9 10 17
Current consumption with blocked rotor LRA
[A]
12 19 19 24 37 43 62
Current consumption, operation *2 [A] 60 Hz 2.4 - 2.9 3.5 - 4.9 3.5 - 5.2 4.5 - 7.7 6 - 8.7 6.5 - 10.8 8.5 - 13.7
Max. starting current intake, current peak [A]
60 Hz
15 25 25 34 47 54 69
Starting current intake RMS40 [A] 60 Hz *3 5 16 15 21 30 35 44
Starting current intake RMS300 [A] 60 Hz *4 4 10 10 12 20 22 41
Max. starting current intake, current peak
with soft start [A] 60 Hz
13 14 14 15 26 28 40
Current consumption RMS40 with soft start
[A] 60 Hz *3
5 8 8 9 15 17 23
Current consumption RMS300 with soft start
[A] 60 Hz *4
4 6 6 7 12 13 20
Fan output, free-blowing [m³/h] (cfm)
275
(162)
275
(162)
400
(235)
500
(294)
625
(368)
625
(368)
2x550
(2x324)
Supply air grille [cm²] 150 235 235 250 390 390 650
Air inlet grille [cm²] 325 490 490 550 800 800 1600
Minimum thickness insulation air duct [mm]
(inch)
5mm
Recommended line fuse protection [A] 16 20 *5
Fan connection [mm] (inch)
100,
(4)
125,
(5)
2x125
(2x5)
ø Sea water connection [mm] (inch) 19, 3/4‘‘ 19, 3/4'' 19, 3/4'' 19, 3/4'' 19, 3/4'' 19, 3/4'' 19, 3/4''
Minimum sea-water flow rate [l/min] 50 Hz 6 8 10 12 14 17 21
Minimum sea-water flow rate [l/min] 60 Hz 7.5 10 12 14 17 20 25
Recommended sea water pump 50Hz *6
WB250 WB350
WB350 /
WB500G
WB500 /
WB500G
WB500 /
WB500G"
WB1000 /
WB1000G
Recommended sea water pump 60Hz *6
WB500 /
WB1000G
WB1000 /
WB1000G
max. permissible ambient temperature [°C] +40°C
Net weight [kg] 20 20 22 27 31 34 46
Dimensions of self-contained air-conditioning
unit (LxDxH) [mm] (inch) See also Fig.19 on
page 32 and Fig.20 on page 33.
400 x 320 x 305
(15.7 x 12.6 x
12.0)
400 x 320 x 305
(15.7 x 12.6 x
12.0)
475 x 310 x 310
(18.7 x 12.2 x
12.2)
500 x 350 x 320
(19.7 x 13.8 x
12.6)
540 x 350 x 370
(21.3 x 13.8 x
14.6)
590 x 340 x 370
(23.2 x 13.4 x
14.6)
570 x 510 x 410
(22.4 x 20.1 x
16.1)
Refrigerant quantity R410a [g] 450 250 280 420 550 520 670
Min. sea water temperature in heating mode
[°C]
6
Max. sea water temperature in cooling mode
[°C]
35
*1 BTU/h and electrical data are based on 7 °C evaporation temperature and 38 °C condensation temperature
*2 Current consumption of self-contained air-conditioning unit is dependent on compressor output. Maximum values under tropical conditions.
*3 Effective value of current consumption (RMS) for the self-contained air-conditioning unit for the first 40ms
*4 Effective value of current consumption (RMS) for the self-contained air-conditioning unit for the first 300ms
*5 Compressor only
*6 Only a recommendation. The pump size must be adjusted to the application so that the minimum flow rate is ensured.
