BlueCool S-Series 31
13.1 Self-contained air-conditioning units BlueCool S-Series 115 V
Type
S6-R-115V-
REV-R410a
S8-R-115V-
REV-R410a
S10-R-115V-
REV-R410a
S13-R-115V-
REV-R410a
S16-R-115V-
REV-R410a
Cooling capacity [BTU/h] *1 6,000 8,000 10,000 13,000 16,000
Cooling capacity [kW] *1 1.8 2.4 2.9 3.8 4.7
Rated voltage [V] 115
Frequency [Hz] 60
Current consumption, operation [A] 60Hz *2 3.6 - 5.5 4.5 - 6.1 5.6 - 7.9 7.6 - 11 8.0 - 15.7
Max. starting current intake, current peak [A]
60 Hz
39 54 55 70 89
Starting current intake RMS40 [A] 60 Hz *3 25 35 36 47 59
Starting current intake RMS300 [A] 60 Hz *4 19 20 21 30 35
Current consumption with blocked rotor LRA
[A]
27 34 37 57 70
Fan output, free-blowing [m³/h] (cfm)
275
(162)
275
(162)
350
(206)
430
(253)
650
(382)
Supply air grille [cm²] 150 235 235 250 390
Air inlet grille [cm²] 325 490 490 550 800
Minimum thickness insulation air duct [mm]
(inch)
4
Recommended line fuse protection [A] 16
25 *
5
Fan connection [mm] (inch)
100,
(4)
125,
(5)
ø Sea water connection
[mm] (inch)
19, 3/4‘‘ 19, 3/4'' 19, 3/4'' 19, 3/4'' 19, 3/4''
Minimum sea-water flow rate [l/min] 60 Hz 6 8 10 12 14
Recommended sea water pump 60Hz *6 WB250 WB350 WB350 / WB500G WB500 / WB500G
max. permissible ambient temperature [°C] +40
Net weight [kg] 18 18 20 25 28
Dimensions of self-contained air-conditioning
unit (LxDxH) [mm] (inch) See also Fig.19 on
page 32 and Fig.20 on page 33.
400 x 320 x 305
(15.7 x 12.6 x 12.0)
400 x 320 x 310
(15.7 x 12.6 x 12.2)
475 x 330 x 320
(18.7 x 13.0 x 12.6)
500 x 350 x 325
(19.7 x 13.8 x 12.8)
540 x 350 x 380
(21.3 x 13.8 x 15)
Refrigerant quantity R410a [g] 440 260 240 420 400
Min. sea water temperature in heating mode
[°C]
6
Max. sea water temperature in cooling mode
[°C]
35
*1 BTU/h and electrical data are based on 7 °C evaporation temperature and 38 °C condensation temperature
*2 Current consumption of self-contained air-conditioning unit is dependent on compressor output. Maximum values under tropical conditions.
*3 Effective value of current consumption (RMS) for the self-contained air-conditioning unit for the first 40ms
*4 Effective value of current consumption (RMS) for the self-contained air-conditioning unit for the first 300ms
*5 Compressor only
*6 Only a recommendation. The pump size must be adjusted to the application so that the minimum flow rate is ensured.
