BlueCool S-Series 41
14.3.6 Wiring diagram BlueCool S-Series, S20 and S27 with soft start (230 V systems only)
Fig.24
USB-Diagnosis
Control Panel
Cabin Temp. Sensor
High pr
essure switch
Low pressure switch
A
ttention!
Please look at the label, make sur
e this is the right
ECU with part number WBCL050930B or higher
Fan
Ferrit
Distribution board
4/2 Way reverse
(cycle) Valve
Sea Water Pump
Compressor
Wiring diagram BlueCool S-Series, S20 and S27 with soft start (230 V systems only)
