Audi A1
1 Horn
2 Original vehicle nut
3 Angle bracket
Installing
angle
bracket
1 Copy hole pattern, 7mm dia. hole
Drilling
hole
1 M6x20 bolt, flanged nut
Installing
horn
1
Drill out hole to 8.5 mm dia.
Preparing
perforated
bracket A
3
32
2
1
33
1
20
15
34
1
25
40
35
1
