Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
33
Audi A1
Inserting
FuelFix
Move FuelFix connection piece 2 over
closed stub
1.
Inserting
FuelFix
Work steps F5.3 and F5.4.
Turn FuelFix
1 in position as shown.
Position-
ning FuelF-
ix
Work step F6.
1 FuelFix
2 Hose section, 10mm dia. clamp [2x]
3 Fuel line
Connect-
ing fuel line
100
101
2
1
102
1
103
2
1
3
