Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
34
Audi A1
Work step F7.
F
Installing
FuelFix
Work step F8.
Checking
firm seating
of FuelFix
1 FuelFix installed
2 Fuel line of FuelFix
3 Cable tie as tension relief
Securing
fuel line
All vehicles.
Ensure sufficient distance from neighbour-
ing components, correct if necessary.
1 Cable tie
2 Fuel line of FuelFix
3 Hose section, 10mm dia. clamp [2x]
Connect-
ing meter-
ing pump
0 mm
F 7.1.
<1... 0 mm
F 7.2.
200 min
-1
90°
50 - max
F 7.3.
F 7.4.
F 7.5.
F 7.6.
104
105
106
2
1
3
107
2
3
1
