Audi A1
Route hose section A and connect to cir-
culating pump
Connecting
circulating
pump
1 10x25 hose bracket
2 25x28 hose bracket
Inserting
hose brack-
et
1 Engine outlet hose section
Connecting
engine out-
let
Attach original vehicle wiring harness 2 if
necessary with cable ties.
1 Cable ties
Routing in
engine
compart-
ment
149
A
150
1
2
A
D
151
1
A
152
D
A
1
1
2
