Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
42
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
1 Engine outlet hose section
2 Heat exchanger inlet hose section
X =
Cutting
point
1
Heat exchanger inlet hose section
Connect-
ing heat ex-
changer
inlet
1
Engine outlet hose section
Connect-
ing engine
outlet
Golf VII / Golf VII Sportsvan, Version 2
Remove engine outlet / heat exchanger in-
let hose
1. Spring clips will be reused!
Cutting
point
118
1
40
40
X
2
119
F
1
120
A
1
121
1
