Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
41
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
A =1070
F =990
Cutting
hoses to
length
1
M6 flanged nut, original vehicle stud
bolt
2 Perforated bracket
Installing
perforated
bracket
1
M6x30 spacer nut, original vehicle
stud bolt
Installing
spacer nut
Golf VII / Golf VII Sportsvan, Version 1
Remove engine outlet / heat exchanger in-
let hose
1. Spring clips will be reused!
Cutting
point
FA
114
1
2
115
1
116
117
1
