TRC66-86 *** 21
2.4.6 Checking the Charge of the Remote
Control Unit
- Operate the switch (16/1) to turn on the sender.
- The green light-emitting diode (16/2) flashes to indicate the
correct order transmission by the sender.
When the red diode (16/3) lights up, an acoustic
signal is given, too. From now on, the remaining
capacity of the accumulator will be enough for
approx.15 minutes only.
- When the red light-emitting diode (16/3) flashes, charge the
accumulator as described in paragraph 4.3.3.
2.4.5.2 Checking the Deadman Switch
- Start the compactor (refer to paragraph 2.5).
- Reverse the compactor (refer to paragraph 2.6).
- Actuate the deadman handle (15/1).
The travel drive is switched off. The compactor and the
vibration system must stop.
- Move both drive levers (13/1) to the front.
The deadman control is overridden and the compactor moves
forward.
Figure 14
Figure 15
1
1
Figure 16
2
3
1
