TRC66-86 *** 35
3.3 Description of the Maintenance
Work
3.3.1 Changing the Engine Oil
- Put the compactor out of operation as described in
paragraph 2.9.
Caution!
Drain the engine oil at working temperature only.
- Remove the fastening screws (1/1) on both sides of the
engine hood (1/2).
- Fold the engine hood (2/1) to the front.
- Secure the engine hood (3/1) by means of the hood strut
(3/2).
- Put an appropriate drain pan under the outlet.
Figure 1
Figure 2
Figure 3
1
1
2
2
1
