Weber Genesis 330 User Manual

10
GAS INSTRUcTIONS
2
5
6
1
4
3
Installation Outside of Cabinet
If the cylinder you have does not meet the cylinder type and size guidelines: Mount
the cylinder on the cylinder hanger or place the cylinder on the ground. Either way the
cylinder must be placed outside the base cabinet, on the right side of the grill.
Cylinder Hanger Installation
You will need: the cylinder hanger bracket (1) and cylinder hanger (2).
A) Position the cylinder hanger bracket on the right outside panel of the grill. Fasten
with screws, washers and nuts (3).
B) Install the cylinder glides (4) into the two holes below the cylinder hanger bracket.
Fasten with screws, washers and nuts.
C) Turn the cylinder so the valve opening faces the front of the barbecue.
D) Hold the cylinder hanger and tilt the cylinder so the two bent supports of the
cylinderhangerarelocatedunderneaththecylinderbaseflange.Adjustthelength
of the belt to the cylinder, and snap ends together (5).
E) Lift and place the cylinder hanger on the cylinder hanger bracket as shown (6).
Ground Placement
A) Place the cylinder on the ground, outside the base cabinet, on the right side of the
grill (7).
B) Turn the LP cylinder so the opening of the valve is facing the front of the Weber
®
gas
barbecue.
◆
7
The grill illustrated may
have slight differences
than the model purchased.

Weber Genesis 330 Specifications

General

BTU Main Burners	38, 000
BTU Sear Burner	10, 000
BTU Side Burner	12, 000
Grate Material	Porcelain-enameled cast iron
Burner Material	Stainless Steel
Ignition	Electronic
Fuel Type	Propane
Burners	3
Warranty	10 years
