Weber Genesis 330 User Manual

WWW.WEbER.cOm
®
13
GAS INSTRUcTIONS
LEAK-CHECK PREPARATION
m WARNING: The gas connections of your gas grill have been
factory-tested. We do, however, recommend that you leak-
check all gas connections before operating your gas grill.
Remove Control Knobs & Control Panel for Leak Testing
You will need: Phillips & flathead screwdrivers.
A) Locate door pin release in door assembly. Using a screwdriver, push down on door
pin release (1) until door detaches from frame assembly. Pull top of door away from
frame assembly (2) andliftdooroffbottomadjustablehingepin.
B) Remove control knobs, igniter button, retention nut, and battery (3).
C) Remove screws from wind deflector with a Phillips screwdriver (4).
D) Tilt end of wind deflector down and slide wind deflector away to remove (5).
E) Let igniter module dangle from wires. Do not disconnect (6).
F) Remove screws from underside of control panel with Phillips screwdriver (7).
G) Lift control panel up slightly, tilt up front edge and gently lift up (8).
H) Replace control panel and wind deflector when leak check is completed.
◆
3
4
5
6
7
8
1
2
The grill illustrated may
have slight differences
than the model purchased.

Weber Genesis 330 Specifications

General

BTU Main Burners	38, 000
BTU Sear Burner	10, 000
BTU Side Burner	12, 000
Grate Material	Porcelain-enameled cast iron
Burner Material	Stainless Steel
Ignition	Electronic
Fuel Type	Propane
Burners	3
Warranty	10 years
