Weber Genesis 330 User Manual

WWW.WEbER.cOm
®
11
GAS INSTRUcTIONS
PREPARE TO CONNECT THE LP CYLINDER
The regulator must be secured to the side panel with the supplied hose retention
bracket.
Installation Inside of Cabinet
A) Open base cabinet doors.
B) Slide hose retention bracket (1) along hose to align with inside right panel front
mounting holes. Secure with two Phillips head screws/washers/bolts (2).
m WARNING: The hose must be secured to the side panel with
the hose retention bracket. Failure to do so could cause
damage to the hose resulting in a fire or explosion, which
can cause serious bodily injury or death, and damage to
property.
Note: Be sure the cylinder brackets are installed in the base panel and the base of the
cylinder fits within the cylinder brackets.
1
2
1
2
Installation Outside of Cabinet
A) Open base cabinet doors.
B) Pass the regulator hose and hose retention bracket (1) out through the side panel
opening.
C) Align with side panel mounting holes located beneath the side panel opening.
Secure with two Phillips head screws/washers/bolts (2).
m WARNING: The hose must be secured to the side panel with
the hose retention bracket. Failure to do so could cause
damage to the hose resulting in a fire or explosion, which
can cause serious bodily injury or death, and damage to
property.
◆

Weber Genesis 330 Specifications

General

BTU Main Burners	38, 000
BTU Sear Burner	10, 000
BTU Side Burner	12, 000
Grate Material	Porcelain-enameled cast iron
Burner Material	Stainless Steel
Ignition	Electronic
Fuel Type	Propane
Burners	3
Warranty	10 years
