Weber Genesis 330 User Manual

8
GAS INSTRUcTIONS
CYLINDER INSTALLATION LOCATION OPTIONS
Pick one of three options to determine the location of the cylinder; install inside the
cabinet, mount on the cylinder hanger, or place the cylinder on the ground. The type and
size of cylinder you purchase will help determine the cylinder installation location.
Installation Inside of Cabinet
The LP gas cylinder can be connected inside the grill cabinet as long as the cylinder
meets the cylinder size guidelines (1). There are several factors that will determine
whether a cylinder may be safely used inside your grill cabinet:
A) The base of the cylinder must fit between the cylinder brackets and rest flat on the
base panel.
Cylinder Dimensions
Height 465 mm maximum
Width 289 mm - (rectangular footprint) or
318 mm (round footprint) maximum
B) Cylinder Capacity
6 kg maximum
Several possible cylinder models are illustrated with approved dimensions (2).
m WARNING: If the LP cylinder that you purchased does not
meet the cylinder size requirements, do not attempt to
connect the cylinder inside the cabinet. Mount the cylinder
on the cylinder hanger, or place on the ground. Failure to
do so could cause damage to the hose resulting in a fire
or explosion, which can cause serious injury or death, and
damage to property.
◆
PRIMAGAZ 5.2 kg
BP 5 kg
BUTAGAZ 6 kg
CALOR 5 kg
2
289 / 318 mm
465 mm
1

Weber Genesis 330 Specifications

General

BTU Main Burners	38, 000
BTU Sear Burner	10, 000
BTU Side Burner	12, 000
Grate Material	Porcelain-enameled cast iron
Burner Material	Stainless Steel
Ignition	Electronic
Fuel Type	Propane
Burners	3
Warranty	10 years
