26
mAINTENANcE
BURNER TUBES CLEANING OR REPLACEMENT
You will need: Phillips screwdriver, flathead screwdriver, and 5/16" nut-driver.
A) Your Weber
®
gas barbecue must be OFF and cool.
B) Turn gas OFF at source.
C) Remove cookbox components - warming rack, grates and Flavorizer
®
bars. (Heat
deflectors do not need to be removed.)
Control Panel Removal
To remove control panel:
A) Locate door pin release in door assembly. Using a screwdriver, push down on door
pin release (1) until door detaches from frame assembly. Pull top of door away from
frame assembly (2) andliftdooroffbottomadjustablehingepin.
B) Remove control knobs, igniter button, igniter retention nut, and battery (3).
C) Remove screws from wind deflector (4) located underneath the control panel with a
Phillips screwdriver.
D) Tilt end of wind deflector down and slide away to remove (5).
E) Remove igniter module from control panel (6) and remove all four wires from
module.
F) Remove screws from underside of control panel with Phillips screwdriver (7).
G) Lift control panel up slightly, tilt up front edge and gently lift up and away (8).
3
4
5
6
7
8
1
2
The grill illustrated
may have slight
differences than the
model purchased.

Weber Genesis 330 Specifications

General

BTU Main Burners	38, 000
BTU Sear Burner	10, 000
BTU Side Burner	12, 000
Grate Material	Porcelain-enameled cast iron
Burner Material	Stainless Steel
Ignition	Electronic
Fuel Type	Propane
Burners	3
Warranty	10 years
