Weber Genesis 330 - Exploded View List

WWW.WEbER.cOm
®
5
1. Thermometer
2. Thermometer Bezel
3. Shroud
4. Handle
5. Warming Rack
6. Left Side Table
7. Cooking Grate
8. Burner Tube
9. Flavorizer
®
Bar
10. Igniter
11. Cookbox
12. Heat Deflector
13. Slide-Out Grease Tray
14. Rear Frame Support
15. Disposable Drip Pan
16. Catch Pan
1 7. Catch Pan Holder
18. Left Frame Panel
19. Front Frame Support
20. Left Door
21. Right Door
22. Door Handle
23. Shroud Hardware
24. Side Burner
25. Right Side Table
26. Side Burner Gas Line
2 7. Manifold
28. Heat Shield
29. Wire Clip
30. Control Panel
31. Sear Burner Heat Shield
32. Igniter Button
33. Igniter Module
34. Wind Deflector
35. Control Knob
36. Sear Station
®
Knob
3 7. Manifold Hose
38. Bulkhead
39. Hose Retention Bracket
40. Hose / Regulator
41. Right Frame Panel
42. Back Panel
43. Bottom Panel
44. Cylinder Hanger Bracket
45. Cylinder Hanger
46. Cylinder Glide
4 7. Cylinder Brackets
48. Caster
49. Matchstick Holder
50. Locking Caster
EXPLODED VIEW LIST
