WEG ECW500 - Page 17

Quick Parameter Reference
ECW500 | 9
Modbus
Address
Description
Adjustable Range
Factory
Setting
Setting
Proper
.
30450
PTUV delay
0.5 to 60.0 s
20.0 s
30452
PTUV level
40 to 100 % (V
nom
)
40 %
Excitation Overcurrent (PEOC)
30454
PEOC enable
0 = False, 1 = True
0
30456
PEOC level
0.1 to 30.0 A
30 A
30458
PEOC delay
0.1 to 30.0 s
1.0 s
Rotating Diodes (PED)
30460
Limit 1st Harmonic PED
0.1 to 100.0 %
60.0 %
30462
Limit 2st Harmonic PED
0.1 to 100.0 %
60.0 %
30464
Ripple Maximum PED
0.1 to 100.0 %
60.0 %
30466
Enable PED
0 = False, 1 = True
0
30468
Delay PED
5 to 60 s
60 s
30470
PED Turn Off ECW500
0 = False, 1 = True
0
Loss of Analog Current Input (PLCI)
31024
PLCI Enable
0 = False, 1 = True
1
31026
PLCI Delay
0 to 5 s
1 s
HMI
30078
Password
1 to 999
2
30080
New password
0 to 999
2
30082
Time to show message on HMI
0 to 9000 ms
500 ms
30084
Time to hide message on HMI
0 to 9000 ms
8000 ms
30086
Fast key multiplier
0 to 300
2
30088
Super fast key multiplier
0 to 3000
10
30090
Ultra fast key multiplier
0 to 3000
20
30092
LCD Contrast
0 to 31
31
30094
Calendar Month
1 to 12
1
30096
Calendar Day
1 to 31
1
30098
Calendar Year
2000 to 2200
2010
30100
Calendar Week day
0 = Sunday
0
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
30102
Time - Hours
0 to 23
0
30104
Time - Minutes
0 to 59
0
30106
Time - Seconds
0 to 59
0
30114
HMI language
0 = English
0
1 = Portuguese
2 = NA
3 = NA
30116
Enable HMI on/off buttons
0 = Off, 1 = On
1
31320
Button F1 function
0 = Disabled
0
1 = Reference increment
2 = Reference decrement
31322
Button F2 function
0 = Disabled
0
1 = Reference increment
2 = Reference decrement
31324
Increment / Decrement Button F1
0 a 100 %
0 %
31326
Increment / Decrement Button F2
0 to 100 %
0 %
START-UP RAMP / CALIBRATION
