Quick Parameter Reference .
8 | ECW500
Modbus
Address
Description
Adjustable Range
Factory
Setting
Setting
Proper
.
30398
RL0 LEOC acting
0 = False, 1 = True
0
30400
RL1 LEOC acting
0 = False, 1 = True
0
30402
RL2 LEOC acting
0 = False, 1 = True
0
30404
RL3 LEOC acting
0 = False, 1 = True
0
30406
RL0 LTOC acting
0 = False, 1 = True
0
30408
RL1 LTOC acting
0 = False, 1 = True
0
30410
RL2 LTOC acting
0 = False, 1 = True
0
30412
RL3 LTOC acting
0 = False, 1 = True
0
30414
RL0 U/F acting
0 = False, 1 = True
0
30416
RL1 U/F acting
0 = False, 1 = True
0
30418
RL2 U/F acting
0 = False, 1 = True
0
30420
RL3 U/F acting
0 = False, 1 = True
0
31206
RL0 Anybus Offline
0 = False, 1 = True
0
31208
RL1 Anybus Offline
0 = False, 1 = True
0
31210
RL2 Anybus Offline
0 = False, 1 = True
0
31212
RL3 Anybus Offline
0 = False, 1 = True
0
31332
RL0 Power Failure Phase
0 = False, 1 = True
0
31334
RL1 Power Failure Phase
0 = False, 1 = True
0
31336
RL2 Power Failure Phase
0 = False, 1 = True
0
31338
RL3 Power Failure Phase
0 = False, 1 = True
0
31340
RL0 Loss of Excitement
0 = False, 1 = True
0
31342
RL1 Loss of Excitement
0 = False, 1 = True
0
31344
RL2 Loss of Excitement
0 = False, 1 = True
0
31346
RL3 Loss of Excitement
0 = False, 1 = True
0
PROTECTIONS
Feedback Loss (PFL)
30286
Enable PFL
0 = Disabled, 1 = Enabled
1
30288
Enable PFL to MECC
0 = Disabled, 1 = Enabled
1
30290
PFL delay
0.0 to 30.0 s
0.2 s
30292
PFL balanced level
0.0 to 100.0 %
15.0 %
30294
PFL unbalanced level
0.0 to 100.0 %
15.0 %
Excitation Loss (PEL)
30296
PEL delay
1 to 100 s
5 s
30436
PEL enable
0 = Disabled, 1 = Enabled
0
Excitation Overvoltage (PEOV)
30422
Enable PEOV
0 = False, 1 = True
0
30424
PEOV level
1 to 325 Vcc
32 Vcc
30426
PEOV delay
0.2 to 30.0 s
0.2 s
Power Module
30428
Power temperature level
0 to 130 °C
125 °C
30430
Power temperature delay
0 to 30 s
2 s
30432
Power temperature turn off ECW
0 = False, 1 = True
1
30434
Enable phase loss at power
0 = Off, 1 = On
1
30438
Maximum PWM
0.00 to 100.00 %
100.00 %
30440
Minimum PWM
-100.00 to 0.00 %
-100.00 %
30472
Phase loss protection delay
0 a 60 s
3 s
30474
DC link overvoltage delay
0.0 a 10.0
2 s
Terminal Overvoltage (PTOV)
30442
PTOV enable
0 = False, 1 = True
0
30444
PTOV delay
0.5 to 60.0 s
1.0 s
30446
PTOV level
100 to 200 % (V
nom
)
130 %
Terminal Undervoltage (PTUV)
30448
PTUV enable
0 = False, 1 = True
0
