Quick Parameter Reference
ECW500 | 7
Modbus
Address
Description
Adjustable Range
Factory
Setting
Setting
Proper
.
1 = Maintain
2 = Latched
30312
RL1 annunciation type
0 = Momentary
1
1 = Maintain
2 = Latched
30314
RL2 annunciation type
0 = Momentary
1
1 = Maintain
2 = Latched
30316
RL3 annunciation type
0 = Momentary
1
1 = Maintain
2 = Latched
0.1 to 5.0 s
0.1 to 5.0 s
30318
RL0 time
0.1 to 5.0 s
0.2 s
30320
RL1 time
0.1 to 5.0 s
0.2 s
30322
RL2 time
0.1 to 5.0 s
0.2 s
30324
RL3 time
0.1 to 5.0 s
0.2 s
30326
RL0 field overvoltage
0 = False, 1 = True
0
30328
RL1 field overvoltage
0 = False, 1 = True
0
30330
RL2 field overvoltage
0 = False, 1 = True
0
30332
RL3 field overvoltage
0 = False, 1 = True
0
30334
RL0 machine overvoltage
0 = False, 1 = True
0
30336
RL1 machine overvoltage
0 = False, 1 = True
0
30338
RL2 machine overvoltage
0 = False, 1 = True
0
30340
RL3 machine overvoltage
0 = False, 1 = True
0
30342
RL0 machine undervoltage
0 = False, 1 = True
0
30344
RL1 machine undervoltage
0 = False, 1 = True
0
30346
RL2 machine undervoltage
0 = False, 1 = True
0
30348
RL3 machine undervoltage
0 = False, 1 = True
0
30350
RL0 underfrequency
0 = False, 1 = True
0
30352
RL1 underfrequency
0 = False, 1 = True
0
30354
RL2 underfrequency
0 = False, 1 = True
0
30356
RL3 underfrequency
0 = False, 1 = True
0
30358
RL0 overexcitation
0 = False, 1 = True
0
30360
RL1 overexcitation
0 = False, 1 = True
0
30362
RL2 overexcitation
0 = False, 1 = True
0
30364
RL3 overexcitation
0 = False, 1 = True
0
30366
RL0 underexcitation
0 = False, 1 = True
0
30368
RL1 underexcitation
0 = False, 1 = True
0
30370
RL2 underexcitation
0 = False, 1 = True
0
30372
RL3 underexcitation
0 = False, 1 = True
0
30374
RL0 to MECC mode
0 = False, 1 = True
0
30376
RL1 to MECC mode
0 = False, 1 = True
0
30378
RL2 to MECC mode
0 = False, 1 = True
0
30380
RL3 to MECC mode
0 = False, 1 = True
0
30382
RL0 feedback loss
0 = False, 1 = True
0
30384
RL1 feedback loss
0 = False, 1 = True
0
30386
RL2 feedback loss
0 = False, 1 = True
0
30388
RL3 feedback loss
0 = False, 1 = True
0
30390
RL0 excitation diode failure
0 = False, 1 = True
0
30392
RL1 excitation diode failure
0 = False, 1 = True
0
30394
RL2 excitation diode failure
0 = False, 1 = True
0
30396
RL3 excitation diode failure
0 = False, 1 = True
0
