5
DETAILED PARAMETER DESCRIPTION
P0211 - Disable by zero speed (Stop Logic)
Adjustable range: 0 to 1 Factory setting: 1
Acesso: Menu → Configurations → Control
Description:
When active it disables the inverter (general disable) when the speed reference and the actual speed become
lower than the value adjusted in P0291 (Zero Speed Zone) and after the time adjusted in P0213 has elapsed.
The inverter is enabled again when any of the conditions defined in P0212 is fulfilled.
Table 5.23: Disable by zero speed (Stop Logic)
P0211 Function
0
Inactive
1
Active
P0212 - Condition for disabable output by zero speed
Adjustable range: 0 to 1 Factory setting: 0
Acesso: Menu → Configurations → Control
Description:
When the PID Regulator is active (P0203 = 1 or 3) and in automatic mode, besides the condition programmed
in
P0212, it is also necessary that the PID error (the difference between the setpoint and the process variable)
be more than the value programmed in P0535, so that the inverter will be able to leave the zero speed disable.
Table 5.24: Condition for disabable output by zero speed
P0212 Function
0
P0001 (N*) > P0291 or P0002 (N) > P0291
1
P0001 (N*) > 0
P0213 - Time delay for zero speed disable
Adjustable range: 0 to 999 s Factory setting: 0 s
Acesso: Menu → Configurations → Control
Description:
P0213 = 0: stop logic without timing.
P0213 > 0: stop logic with timing. After the speed reference and the motor speed become lower than the
value set in P0291, count of the time set in P0213 begins. When the time count reaches this value, the inverter
will be disabled. When the time programmed at P213 has elapsed the inverter will be disabled. If during that
time count any of the conditions for the disable by stop logic no longer exists, the time count is reset and the
inverter will be enabled again.
P0214 - Line phase loss detection
Adjustable range: 0 to 1 Factory setting: 0
Acesso: Menu → Configurations → Protections
Description:
Line phase loss detection.
MVW3000 | 5-34
