QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0253 AO2 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
5 5-50
P0254 Analog output AO2 gain (MVC4 or EBB
board)
0.000 to 9.999 1.000 5-50
P0255 AO3 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
2 5-51
P0256 Analog output AO3 gain (EBA board) 0.000 to 9.999 1.000 5-51
P0257 AO4 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
5 5-51
P0258 Analog output AO4 gain (EBA board) 0.000 to 9.999 1.000 5-51
