QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0259 AO5 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
2 5-51
P0260 Analog output AO5 gain (unipolar iso-
lated MVC4 board)
0.000 to 9.999 1.000 5-52
P0261 AO6 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
5 5-52
P0262 Analog output AO6 gain (unipolar iso-
lated MVC4 board)
0.000 to 9.999 1.000 5-52
P0263
(1)
DI1 Function 0 = Not Used
1 = Start/Stop
2 = General Enable
3 = Fast Stop
1 5-54
P0264
(1)
DI2 Function 0 = Forward/Reverse
1 = Local/Remote
0 5-54
MVW3000 | 1-9
