QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0240 Analog input AI2 offset (bipolar MVC4
board)
-100.0 to 100.0 % 0.0 % 5-47
P0241
(1)
AI3 signal function 0 = P0221/P0222
1 = Not Used
2 = Maximum torque current
3 = PID process variable
0 5-47
P0242 Analog input AI3 gain (bipolar EBB
board)
0.000 to 9.999 1.000 5-48
P0243
(1)
AI3 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
0 5-48
P0244 Analog input AI3 offset (bipolar EBB
board)
-100.0 to 100.0 % 0.0 % 5-49
P0245 Analog input AI4 gain (bipolar EBA
board)
0.000 to 9.999 1.000 5-49
P0246
(1)
AI4 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
4 = (-10 to +10) V
0 5-49
P0247 Analog input AI4 offset (bipolar EBA
board)
-100.0 to 100.0 % 0.0 % 5-49
P0248 Analog input AI2 ļ¬lter (bipolar MVC4
board)
0.0 to 16.0 s 0.0 s 5-50
P0251 AO1 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor speed
3 = Reserved
4 = Reserved
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Reserved
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Output voltage
2 5-50
P0252 Analog output AO1 gain (MVC4 or EBB
board)
0.000 to 9.999 1.000 5-50
