QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0225
(1)
Selection of JOG Source LOCAL Situa-
tion
0 = Disable
1 = HMI
key
2 = Digital inputs DI3 to DI10 (P0265 to P0272)
3 = Serial
4 = Fieldbus
5 = PLC
6 = Graphic HMI
key
6 5-37
P0226
(1)
Selection of Direction of ROTATION RE-
MOTE Situation
0 = Always forward
1 = Always reverse
2 = HMI key (Forward default)
3 = HMI key (Reverse default)
4 = Digital Input DI2 (P0264 = 0)
5 = Serial (Forward default)
6 = Serial (Reverse default)
7 = Fieldbus (Forward default)
8 = Fieldbus (Reverse default)
9 = AI4 Polarity
10 = Forward PLC
11 = Reverse PLC
12 = Graphic HMI key (Forward)
13 = Graphic HMI key (Reverse)
2 5-38
P0227
(1)
Start/Stop Selection REMOTE Situation 0 = HMI
and
keys
1 = Digital input DIx
2 = Serial
3 = Fieldbus
4 = PLC
5 = Graphic HMI
and
key
0 5-38
P0228
(1)
JOG Selection - REMOTE Situation 0 = Disable
1 = HMI
key
2 = Digital inputs DI3 to DI10 (P0265 to P0272)
3 = Serial
4 = Fieldbus
5 = PLC
6 = Graphic HMI
key
1 5-39
P0231 Actuation in the transition between Lo-
cal and Remote for the HMIG
0 = It keeps the motor state
1 = It keeps the HMI state
2 = It turns off the motor
0 5-43
P0232 Stop Selection 0 = Run/Stop
1 = General disable
0 5-43
P0233 Dead Zone 0 = Inactive
1 = Active
1 5-44
P0234 Analog input AI1 gain (unipolar MVC4
board)
0.000 to 9.999 1.000 5-45
P0235
(1)
AI1 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
0 5-45
P0236 Analog input AI1 offset (unipolar MVC4
board)
-100.0 to 100.0 % 0.0 % 5-46
P0237
(1)
AI2 signal function 0 = P0221/P0222
1 = Not Used
2 = Maximum torque current
3 = PID process variable
0 5-46
P0238 Analog input AI2 gain (bipolar MVC4
board)
0.000 to 9.999 1.000 5-46
P0239
(1)
AI2 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
4 = (-10 to +10) V
0 5-47
MVW3000 | 1-6
