DETAILED PARAMETER DESCRIPTION
Description:
When the option 0 (P0221/P0222) is selected, AI3 is able to receive the speed reference, which will be sub-
jected to the speed limits(P0133 and P0134) and ramp action (P0100 to P0103).
Refer to Figure 5.24 on page 5-40.
The option 3, process variable, defines the AI3 input as the PID regulator feedback signal (e.g., pressure or
temperature sensor, etc.), provided that P0524 = 1.
✓
NOTE!
Isolated Analog Input located on the Optional Board EBB. Refer to the Chapter 7 OPTIONAL AC-
CESSORIES AND BOARDS on page 7-1 of the User’s Manual.
Table 5.40: AI3 signal function
P0241 Function
0
P0221/P0222
1
Not Used
2
Maximum torque current
3
PID process variable
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0242 - Analog input AI3 gain (bipolar EBB board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu → Configurations → I/O → Analog inputs
Description:
Refer to P0234.
P0243 - AI3 Signal Type
Adjustable range: 0 to 3 Factory setting: 0
Acesso: Menu → Configurations → I/O → Analog inputs
Description:
Set the S4.1 switch on the EBB optional board to “ON” position when a current signal is used at the analog
input AI3.
Inverse reference is obtained with the options 2 and 3, i.e., the maximum speed is obtained with the minimum
reference.
Table 5.41: AI3 Signal Type
P0243 Function
0
(0 to 10) V/(0 to 20) mA
1
(4 to 20) mA
2
(10 to 0) V/(20 to 0) mA
3
(20 to 4) mA
✓
NOTE!
This parameter can be changed only with the motor stopped.
