1
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0312
(1)
Type of serial protocol 0 = Not Used
1 = Modbus-RTU, 9600 bps, no parity
2 = Modbus-RTU, 9600 bps, odd parity
3 = Modbus-RTU, 9600 bps, even parity
4 = Modbus-RTU, 19200 bps, no parity
5 = Modbus-RTU, 19200 bps, odd parity
6 = Modbus-RTU, 19200 bps, even parity
7 = Modbus-RTU, 38400 bps, no parity
8 = Modbus-RTU, 38400 bps, odd parity
9 = Modbus-RTU, 38400 bps, even parity
7 5-68
P0313 Disabling with alarm A128, A129 and
A130
0 = Disable via Run/Stop
1 = Disable via General Enable
2 = Inactive
3 = Go to LOCAL
4 = Not Used
5 = Fatal Failure
0 5-68
P0314
(1)
Time for serial watchdog action 0.0 to 999.0 s 0.0 s 5-69
P0315 Function of the MVC3 SCI1 serial chan-
nel
0 = Service HMI
1 = Modbus serial for Tecsystem module
2 = Modbus Serial for Pextron module
0 5-69
P0320
(1)
Flying Start/Ride-Through 0 = Inactive
1 = Flying Start
2 = Flying Start and Ride-Through
3 = Ride-Through
0 5-70
P0331 Voltage ramp time 0.2 to 50.0 s 8.0 s 5-70
P0332 Dead time 1.0 to 40.0 s 10.0 s 5-70
P0333 Ride-through time 0.0 to 20.0 s 10.0 s 5-70
P0400
(1)(4)
Motor rated voltage 1 to 19999 V 6600 V 5-71
P0401
(1)
Motor rated current 0.1 to 3705.0 A 140.0 A 5-72
P0402
(1)
Motor rated speed 1 to 7200 rpm 1796 rpm 5-72
P0403
(1)
Motor Rated Freq 1 to 120 Hz 60 Hz 5-72
P0405
(1)
Speed sensor data (encoder) 100 to 9999 PPR 1024 PPR 5-72
P0406
(1)(2)
Ventilation Type 0 = Self-ventilated
1 = Separated ventilation
0 5-73
P0408
(1)
Run Self-tuning 0 = No
1 = Self Gain
1 5-73
P0409 Motor stator resistance Rs 0.000 to 9.999 Ω 0.000 Ω 5-73
P0410 Motor magnetization current (Imr) 0.0 to 1024.0 A 0.0 A 5-74
P0411 Motor Flux Leakage Inductance 0.00 to 99.99 mH 0.00 mH 5-74
P0412 Lr/Rr Constant 0.000 to 9.999 s 0.000 s 5-74
P0413 Tm Time Constant 0.00 to 99.99 s 0.00 s 5-74
P0414 Magnetizing voltage 0.0 to 20.0 % 0.0 % 5-75
P0427 Inductance LD sigma 0.00 to 99.99 mH 4.85 mH 5-75
P0428 Inductance LQ sigma 0.00 to 99.99 mH 4.41 mH 5-76
P0429 Resistence RD 0.000 to 9.999 Ω 1.139 Ω 5-76
P0430 Resistance RQ 0.000 to 9.999 Ω 0.831 Ω 5-76
P0431 Number of motor poles 2 to 64 4 5-76
P0436 Lf inductance 0.0 to 999.9 mH 88.0 mH 5-77
MVW3000 | 1-19
