QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0437 Resistence Rf 0.000 to 9.999 Ω 0.047 Ω 5-77
P0438 Proportional gain of the current regulator
IQ
0.000 to 9.999 0.034 5-77
P0439 Integration constant of the current regu-
lator IQ
0.1 to 999.9 9.0 5-78
P0440 Proportional gain of the current regulator
ID
0.000 to 9.999 0.074 5-78
P0441 Integration constant of the current regu-
lator ID
0.1 to 999.9 19.6 5-78
P0446 Base field current 0.1 to 999.9 A 33.3 A 5-79
P0449 Maximum field current (Brushless) 0.01 to 5.00 PU 0.70 PU 5-79
P0450 Minimum field current (Brushless) 0.01 to 5.00 PU 0.01 PU 5-79
P0451 Minimum field for soft-start function 0.01 to 5.00 PU 0.15 PU 5-79
P0452 Field input frequency 0.0 to 60.0 Hz 0.0 Hz 5-80
P0453 Field ramp time 0.00 to 30.00 s 1.00 s 5-80
P0454 Coefficient A1 of the Polynomial of the
magnetic saturation curve
0.000 to 9.999 0.000 5-81
P0455 Coefficient B1 of the Polynomial of the
magnetic saturation curve
0.000 to 9.999 0.174 5-81
P0456 Coefficient C1 of the Polynomial of the
magnetic saturation curve
0.000 to 9.999 1.059 5-82
P0464 Maximum compensation current of PF 0.00 to 1.00 PU 0.80 PU 5-82
P0490 Graphic HMI LCD contrast adjustment 50 to 150 110 5-83
P0491
(1)
HMI commands configuration 0 = Inactive
1 = Local HMI
2 = Remote HMI
0 5-83
P0493 Sampling time of the online graphic 1 to 100 x 10 ms 10 x 10 ms 5-83
P0500 Read-only parameter 1 selection 0 = Inactive
1 = Motor speed reference
2 = Motor speed
3 = Motor Current
4 = Reserved
5 = Motor Frequency
6 = Output voltage
7 = Motor Torque
8 = Inverter output power
9 = Value of process variable (PID)
2 5-83
P0501 Read-only parameter 2 selection 0 = Inactive
1 = Motor speed reference
2 = Motor speed
3 = Motor Current
4 = Reserved
5 = Motor Frequency
6 = Output voltage
7 = Motor Torque
8 = Inverter output power
9 = Value of process variable (PID)
0 5-83
