Installation and Operation Manual - SSW-05 Plus
20. TABLE OF PARAMETERS (FOR SERIAL COMMUNICATION / HMI-SSW05-RS):
P000
(2)
Parameter Access
0 ... 4, 6... 9999 = Read
0- 24
5 = Alteration
P002 Motor Current Indication (%) 000,0 to 999,9 % In 24
P003 Motor Current Indication (A) 000,0 to 999,9 A 24
P023 Software Version - 24
P030 R Phase Current 000,0 to 999,9 A 24
P031 S Phase Current 000,0 to 999,9 A 24
P032 T Phase Current 000,0 to 999,9 A 24
P050
Status Indication of the 0 to 250 -
24
motor overload protection 250 = error
Parameter
Parameter Function Range of the Factory
Unit
User
Page
(Reading) Internal Values Setting Setting
(1)
These Parameters can be changed only with stopped motor.
(2)
These Parameters are not changed through the function “Loads Parameters with Factory Setting” (P204).
P101 Initial voltage 30 to 80 30 % Un 24
P102 Time of the Acceleration Ramp 1 to 20 10 s 24
P104 Time of the Deceleration Ramp 0 to 20 0 = off s 25
P105
(1)
Motor Current Setting 30 to 100 100 % 25
P106
(1)
Protection Configuration 0 to 3F Hexadecimal 1F Hex. - 25
P204
(1)
Load Factory Setting
0 = No function
0- 28
1 = No function
2 = No function
3 = No function
4 = No function
5 = Load factory default
P206 Auto-Reset Time 1 to 1200 900 s 28
P215
(1)
Keypad Copy Function
0 = Off
0- 28
1 = Copy (SSW->keypad)
2 = Paste (keypad->SSW)
P220
(1)
HMI/(Trimpots and Dip Switch) 0 = Trimpots and Dip Switch
0- 29
Selection 1 = HMI
P264
(1)
Programmable Digital Input
0 = Not used
1- 29
DI 1
1 = Enable / Disable
2 = External Fault
P277
(1)
Programmable relay output
1 = Full voltage
1- 29
(14/23 - 24)
2 = Error
3 = Serial Com.
P295
(1) (2)
Rated current of the Soft-Starter
0 = 3 A
-29
1 = 10 A
2 = 16 A
3 = 23 A
P308 Network Address 1 to 30 1 - 30
P313
Action of the serial
1 = only Error
1
-
30
communication verification
2 = ramp disabling
3 = General disabling
4 = P2641
P314
Verification Time of the
0 to 5 0 = OFF s 30
Serial Communication
P610 Immediate Undercurrent 30 to 100 30 (%) 30
P611 Immediate Undercurrent Time
1 to 99
0 (s) 30
0 = Disabled
Parameter
Parameter Function Range of the Factory
Unit
User
Page
(Reading and Writing) Internal Values Setting Setting
According
to the
Type
4 = 30 A
5 = 45 A
6 = 60 A
7 = 85 A
