Installation and Operation Manual - SSW-05 Plus
5. SSW-05 PLUS DESCRIPTION:
7. TABLE OF CONNECTOR TORQUE SETTINGS:
SSW-05 Plus
Size
1
2
Torque-Power Terminals
(R, S, T, U, V and W)
Nm (lb-in)
3.0 (32.7)
5.5 (60.0)
Nm (lb-in)
0.5 (4.5)
0.5 (4.5)
Torque of
Electronics Terminal
* According to able 45.2, UL508.
** Valid for Standard 4 pole WEG motors.
6. TABLE OF POWERS / CURRENTS / POWER WIRING (COPPER WIRE AT 70°C (158
O
F)):
Model
SSW-05.3
SSW-05.10
SSW-05.16
SSW-05.23
SSW-05.30
SSW-05.45
SSW-05.60
SSW-05.85
Rated
Current
3A
10A
16A
23A
30A
45A
60A
85A
220Vto240V*
HP kW
0.75 0.55
3 2.2
5 3.7
7.5 5.5
10 7.5
15 11
20 15
30 22
380Vto415V*
HP kW
1.5 1.1
5 3.7
7.5 5.5
10 7.5
15 11
25 18.5
30 22
50 37
440Vto480V*
HP kW
1.5 1.1
5 3.7
10 7.5
15 11
20 15
30 22
40 30
60 45
Power Wiring
mm
2
(AWG)
0.75 (18)
1.5 (16)
4 (12)
6 (10)
10 (8)
16 (6)
25 (4)
35 (2)
Size
1
2
525V**
kW
1.5
5.5
11
15
18.5
30
45
55
575V*
HP
2
7.5
10
20
25
40
50
75
Setting
Trimpots
Reset Button
Dip-switch for
Protection
Enable
Three-phase Input Power Supply
Reset (DI2)
Motor Enable/Disable Command (DI1)
Electronics Power Supply (A1 and A2)
SSW-05 Plus Status LEDS
Relay Output (13, 14/23 and 24)
Output to motor
Connector for Serial
Interface or HMI
Figure 5.1 - SSW05 Plus Front view
