Installation and Operation Manual - SSW-05 Plus
SSW-05 - INSTALLATION AND OPERATION MANUAL
INTRODUCTION
The SSW-05 Plus electronic Soft-Starter has been designed to drive three-phase induction motors
applied to light duty loads, such as centrifugal pumps, small fans and screw compressors. If the
Soft-Starter shall be applied on heavy duty loads, please contact WEG.
The serial communication is available in the SSW-05 with software versions greater than V2.00.
The manual of the serial communication is available for download on the website www.weg.com.br.
With the serial communication is possible:
a)to connect the Soft-Starter in an equipment network, like PC, PLC, and others;
b)to use with SuperDrive software for Microsoft Windows, allowing the SSW-05 programming
and operation;
c)to use the remote HMI (human machine interface) for SSW-05 programming and operation.
SAFETY NOTICES:
The following Safety Notices will be used in this Manual:
Danger
If the recommended Safety Notices are not strictly observed, it can lead to serious or fatal
injuries of personnel and/or material damage.
Attention
Failure to observe the recommended Safety Procedures can lead to material damage.
Note
The content of this Manual supplies important information for the correct understanding of
operation and proper performance of the equipment.
1. SAFETY INSTRUCTIONS:
Danger
Always disconnect the power supply from the equipment before attempting any
maintenance work.
Attention
Personnel must review this entire Manual before attempting to install and operate the
SSW-05 Plus Soft-Starter. Only qualified personnel should plan or implement the
installation, start-up, setting, operation and maintenance of this equipment.
2. WHAT IS THE SSW-05 PLUS SOFT-STARTER:
The SSW-05 Plus Soft-Starter allows smooth start/stop of three-phase induction motors.
3. HOW TO IDENTIFY THE SSW-05 PLUS:
SSW05
Soft-Starter
WEG Series 05
0003
Rated Output
Current:
0003 = 3A
0010 = 10A
0016 = 16A
0023 = 23A
0030 = 30A
0045 = 45A
0060 = 60A
0085 = 85A
T
Three-phase
Power Supply
2246
Power Supply
Voltage:
2246 =
220 to 460V
4657 =
460 to 575V
E
Manual
Language:
P= Portuguese
E= English
S= Spanish
P
SSW-05
Version:
P= Plus
Z
End of Code
T - Trilingual
